Dahi Filling Machine

• Air Consumption
• 150 L/min at 6 bar

• Capacity
• 4000-4800 cups/hour Pcs/hr

• Core Components
• PLC, Motor, Conveyor System, Dosing Pump

• Dimension (L*W*H)
• 2200 mm x 950 mm x 1700 mm Centimeter (cm)

• Driven Type
• Electric

• Filling Material
• Dahi (Curd), Yogurt, Liquid Dairy Products

• Filling Range
• 50 ml to 250 ml (customizable)

• Grade
• Food Grade Stainless Steel (SS304/SS316)

• Motor Power
• 2 HP Horsepower (HP)

• Packaging Type
• Plastic Cups, PP Containers

• Product Type
• Automatic Dahi Filling Machine

• Usage & Applications
• Dahi cup filling & sealing in dairy processing plants

• Voltage
• 220-240 V AC, 50 Hz kilovolt (kV)

• Weight
• 600 kg (Approx.) Kilograms (kg)

• Air Consumption
• Normal

• Capacity
• 500-600 Pcs/hr

• Core Components
• Stainless Steel Structure, Filling Nozzle, Motor, Operative Control Panel

• Dimension (L*W*H)
• 900mm x 750mm x 1350mm Centimeter (cm)

• Driven Type
• Electric

• Filling Material
• Dahi, Curd, Yogurt, and Other Viscous Liquids

• Filling Range
• 50-500 ml (customizable)

• Grade
• Food Grade, SS 304/316

• Motor Power
• 0.5 HP to 1 HP Horsepower (HP)

• Packaging Type
• Cup, Cup-seal, Small Container

• Product Type
• Automatic Dahi Filling Machine

• Usage & Applications
• Industrial

• Voltage
• 220V / 50Hz (Single Phase), available in 415V / 3 Phase kilovolt (kV)

• Warranty
• 1 Year

• Weight
• Approx. 250-350 Kg Kilograms (kg)

• Air Consumption
• 0.5 to 0.8 m3/min, 6-8 bar

• Capacity
• 1000-1200 cups/hour

• Core Components
• PLC, Motor, Pump, Stainless Steel Contact Parts

• Dimension (L*W*H)
• 1800 x 1200 x 2100 mm

• Driven Type
• Electric

• Filling Material
• Dahi, Curd, Yogurt and similar viscous dairy products

• Filling Range
• 50 to 500 ml

• Grade
• Automatic, Food Grade SS304

• Motor Power
• 2 HP

• Packaging Type
• Cup/Container filling

• Product Type
• Automatic Filling Machine

• Usage & Applications
• Filling and packaging of dahi in cups or containers

• Voltage
• 220V/380V, 50/60Hz

• Weight
• Approx. 400 kg

• Air Consumption
• 5 to 6 CFM at 6 Bar

• Capacity
• 1200 to 2400 cups/hour

• Core Components
• Stainless Steel Body, Pneumatic Parts, Motor

• Dimension (L*W*H)
• 1200 x 1200 x 1700 mm (approx)

• Driven Type
• Pneumatic/Mechanical

• Filling Material
• Dahi (Curd), Yogurt, Dairy Products

• Filling Range
• 50 to 500 ml (customizable)

• Grade
• Food Grade SS304/SS316

• Motor Power
• 0.5 HP to 1 HP

• Packaging Type
• Cup, Small Containers

• Product Type
• Rotary Filling Machine

• Usage & Applications
• Cup Filling and Sealing for Curd, Yogurt, Dairy Cups

• Voltage
• 220V/50Hz, Single Phase

• Weight
• Approx. 250-350 kg

• Air Consumption
• 5-6 CFM

• Capacity
• 1800-2400 cups per hour

• Core Components
• Filling Head, Control Panel, Motor, Compressor

• Dimension (L*W*H)
• 1000 mm x 1000 mm x 1500 mm

• Driven Type
• Electric

• Filling Material
• Dahi, Curd, Yogurt

• Filling Range
• 100 ml to 500 ml

• Grade
• Automatic

• Motor Power
• 1 HP

• Packaging Type
• Cup / Container

• Product Type
• Automatic Dahi Filling Machine

• Usage & Applications
• Used for filling dahi or yogurt in cups or containers in dairy industries

• Voltage
• 220V/50Hz, Single Phase

• Weight
• Approx. 350 kg
